ADVANTAGE HYVOLT II Electrical Insulating Oil

ADVANTAGE HYVOLT II Electrical Insulating Oil

PDS Download SDS
101
OVERVIEW



ADVANTAGE HYVOLT II is an electrical insulating naphthenic oil that meets the ASTM D-3487 specification for inhibited oils. Its very low pour point, excellent electrical properties and high level of oxidation stability makes ADVANTAGE HYVOLT II ideal for the demanding requirements of today’s leading transformer manufacturers.



FEATURES & BENEFITS



ADVANTAGE HYVOLT II has very high dielectric strength that exceeds most international requirements and excellent oxidation stability to reduce sludge and acid formation. Its inherent low pour point gives ADVANTAGE HYVOLT II excellent cooling properties and it can be readily mixed with similar ASTM D-3487 oils.

APPLICATIONS





ADVANTAGE HYVOLT II is designed for use in any electrical application requiring an ASTM D-3487 Type II insulated oil.





SPECIFICATIONS



ASTM D-3487

TYPICAL PROPERTIES
TEST DESCRIPTIONTEST METHODSPECIFICATIONSMARKETING VALUES
PRODUCT CODE 101MINMAX
Viscosity, sus at 378°CASTM D 445 66.059.2
Viscosity, SUS at 98.9°CASTM D 445 36.034.0
Viscosity, cSt atLo°CASTM D 445 76.064.2
Viscosity, cSt at 40°CASTM D 34112.09.3
Viscosity, cSt at 100°CASTM D 3413.02.3
Specific Gravity, 156°CASTM D 4052 0.91000.8862
Flash Point, COC, °CASTM D 92 145155
Color, ASTMASTM D 6045 0.5LO.5
Pour Point, °CASTM D 5949 -40-64
Aniline Point, °C ASTM D 611 63.084.074.7
lnterfacial Tension, 25°C, dynes, cm ASTM D 971 4051
Visual Examination ASTM D 1524 Clear & BrightClear & Bright
Electrical Properties
Dielectric BreakLdownL at 60 Hz, Disk electrodes, kV ASTM D 877 3040
Electrical PropertiesASTM D 1816 47
Power Factor at 60 Hz, 25°C, %ASTM D 924 350.050.005
Power Factor at 60 Hz, 100°C, %ASTM D 924 0.300.075
Gassing Tendency, pILlmin ASTM D 2300 3012
Chemical Properties
Oxidation Stability ASTM D 2440
72 hr: Sludge, % by mass 0.1<0.01
Total Acid Number, mg KOHlg 0.3<0.01
164 hr: Sludge, % by mass 0.2<0.01
Total Acid Number, mg KOHlg 0.4<0.01
Oxidation Stability (Rotating Bomb Test), minutes ASTM D 2112 195248
Oxidation Inhibitor Content, wt°/o ASTM D 2668 0.150.300.26
Corrosive Sulfur ASTM D 1275 (B) Noncorrosive Noncorrosive
Water Content, ppm ASTM D 1533 359
Neutralization Number, mg KOHlg ASTM D 974 0.03<0.01
PCB Content, ppm ASTM D 4059 Not detected Not detected
Health and Safety Properties (not an ASTM D 3487 requirement)
Polycyclic Aromatic Compounds, Iwt% IP 346 3<3
Modified Ames Assay ASTM E 1687 PASSPASS
FDA Regulation 21 CFRL178.362Lo (C ) PASSPASS
